Power Supply
Spec
AC Input
85-305Vac/70-430Vdc 0.2A 47~63Hz
Output
3.3V1A, 5V1A, 9V0.56A, 12V0.42A, 15V0.34A, 24V0.21A, 5W max
Output Power
5W max
Efficiency
3.3V＞69%, 5V＞76%, 9V＞77%, 12V＞79%, 15V＞79%, 24V＞81%
No load power consumption
0.15W max
Protections
OCP,SCP
Standard
IEC/EN 60335-1, IEC/EN/UL 62368-1
Certification
