Power Supply
Spec
AC Input
85-305Vac/70-430Vdc 0.12A 47~63Hz
Output
3.3V0.6A, 5V0.6A, 9V0.333A, 12V0.25A, 15V0.2A, 24V0.125A, 3W max
Output Power
3W max
Efficiency
3.3V＞67%, 5V＞72%, 9V＞76%, 12V＞77%, 15V＞78%, 24V＞80%
No load power consumption
0.15W max
Protections
OCP,SCP
Standard
IEC/EN 60335-1, IEC/EN/UL 62368-1
Certification
