25W Open Frame Power Supplies

external power supplies
Key Features
  • Light, extra slim, sleek, compact design
  • Green power, full complies with CEC level V MEPS V EUP2011
  • High power density
  • Extra safe design, have got their respective safety approvals
  • ompleted protect function
Key Applications
  • Set-top-box
  • ADSL
  • Hard disk drive
  • Audio & Video product
  • Household applianec
  • Washing machine
  1. Input
    • Input Voltage : 100 to 120 VAC
    • Frequency : 47-50/60-63hz
    • Input current : 0.8A (Max) 120 /240VAC
    • Inrush current : 50A Max.120VAC at max. Load
    • Leakage current : 0.25 mA Max
  2. Output
    • Over voltage protection
    • Over current protection
    • at 110-200% of lo and Auto-recovery
    • Electronic short circuit protection
    • Operating temperature 0~75℃ Free convection
    • Operating humidity 10-80% RH Non Condensing
    • Sea level Non-operating temperature -20~ 80℃
  3. Safety standards
    • Information technology equipment
    • UL1310
  4. Certificates and approvals
    • UL1310 SAFETY
  5. EMI Emission
    • Radiation Test&Conduction Test: EN 55022/FCC Part 15
    • Harmonic Test : EN 61000-3-2
    • Flicker Test : EN 61000-3-3
  6. EMS immunity
    • ESD Test: EN 61000-4-2
    • RS Test: EN 61000-4-3
    • EFT Test: EN 61000-4-4
    • Surge Test: EN 61000-4-5
    • CS Test: EN 61000-4-6
    • DIP Test: EN 61000-4-11
