36W KSAU036120YYYYM2

external power supplies
Key Features
  • EN60950 ITE Safety Approvals
  • Ambient Temp Range(0℃ to 40℃)
  • ESD:air discharging ±8 KV,contact discharging ±4 KV
  • EMI level B
  • 12V, 3000mA output
Key Applications
  • General I.T.E Use
  • Laptop
  • Set-top-box
  • ADSL
  • Hard disk drive
  • Audio & Video product
  • Household appliance
  1. Input
    • Input Voltage: 90 to 264 VAC
    • Frequency : 47-50/60-63hz
    • Input current: 0.6A (Max)
    • Inrush current : 60A Max. 230VAC at max Load
    • Leakage current: 0.25 mA Max
  2. Output
    • Over voltage protection
    • Over current protection
    • at 110-200% of lo and Auto-recovery
    • Electronic short circuit protection
    • Operating temperature 0~40℃ Free convection
    • Operating humidity 10-90% RH Non Condensing
    • Sea level Non-operating temperature -20~ 80℃
  3. Safety standards
    • Information technology equipment
    • GB4943
  4. Certificates and approvals
    • CCC
  5. EMI Emission
    • Radiation Test&Conduction Test:EN 55022
  6. EMS immunity
    • ESD Test:EN 61000-4-2
    • RS Test:EN 61000-4-3
    • EFT Test:EN 61000-4-4
    • Surge Test:EN 61000-4-5
    • CS Test:EN 61000-4-6
    • DIP Test:EN 61000-4-11
Certificates and approvals
