Sps Desk Top
45W KSUS045 Slim Series
external power supplies
Key Features
- Light, extra slim, sleek, compact design
- Green power, full complies with CEC level V, MEPS V EUP2011
- High power density
- Extra safe design, have got their respective safety approvals
- Completed protect function
Key Applications
- Mobile Devices
- Laptop
- Printer
- Pos
- Set-top-box
- ADSL
- Hard disk drive
- Audio & Video product
- Household applianc
-
Input
- Input Voltage : 90 to 264 VAC
- Frequency : 47-50/60-63hz
- Input current : 1.2A (Max) 100 /240VAC
- Inrush current : 40A Max 120VAC at max Load
- 80A Max 240VAC at max Load
- Leakage current:0.25 mA Max
-
Output
- Over voltage protection
- Over current protection
- at 110-200% of lo and Auto-recovery
- Over temperature protection
- Electronic short circuit protection
- Operating temperature 0~40℃ Free convection
- Operating humidity 10-90% RH Non Condensing
- Sea level Non-operating temperature -20~ 80℃
-
Safety standards
- Information technology equipment
- IEC/EN 60950-1, UL 60950-1, CSA C22.2
- No. 60950-1-03,GB4943
-
Certificates and approvals
- CB , GS , CE , TUV, UL , CCC , FCC,PSE,C-TICK
-
EMI Emission
- Radiation Test&Conduction Test: EN 55022/FCC Part 15
- Harmonic Test : EN 61000-3-2
- Flicker Test : EN 61000-3-3
-
EMS immunity
- ESD Test:EN 61000-4-2
- RS Test:EN 61000-4-3
- EFT Test:EN 61000-4-4
- Surge Test:EN 61000-4-5
- CS Test:EN 61000-4-6
- DIP Test:EN 61000-4-11
Certificates and approvals
