1W KSAP001

external power supplies
Key Features
  • High Power Density
  • Full EN60950 ITE Safety Approval
  • MTBF 50K hours@25℃ (MIL-HDBK-217F)
  • ESD: ±8KV/±15KV,contact discharging±8KV
  • Operating temp Range ( 0℃ to 50℃)
Key Applications
  • General Adapter Use
  • Charger for MP3/MP4
  1. Input
    • Input Voltage: 90 to 264 VAC
    • Frequency : 47-50/60-63hz
    • Input current : 0.15A (Max) 100 /240VAC
    • Inrush current : 50A Max. 120VAC at max Load
    • Leakage current : 0.25 mA Max
  2. Output
    • Over voltage protection
    • Over current protection
    • at 110-200% of lo and Auto-recovery
    • Electronic short circuit protection
    • Ripple&noise 20MHz bandwidth: 200mV
    • Efficiency 52.9% Measured at 25℃
    • Operating temperature 0~40℃ free convection
    • Sea level Non-operating temperature-20~80℃
    • Operating humidity 10-90% RH NonCondensing
  3. Safety standards
    • Information technology equipment
    • EN60950
  4. Certificates and approvals
    • Test report for IEC 60950-1
  5. EMI Emission
    • FCC Part 15 Class B
    • EN55022 class B EN55024 Class B
    • AS/NZS CISPR 22
  6. EMS immunity
    • ESD Test:EN 61000-4-2
    • RS Test:EN 61000-4-3
    • EFT Test:EN 61000-4-4
    • Surge Test:EN 61000-4-5
    • CS Test:EN 61000-4-6
    • DIP Test:EN 61000-4-11
