Sps USB Charger
Mechanical SPEC>

5W KSA01B0500100D5

EXTERNAL POWER SUPPLIES
Key Features
  • Light and portable
  • High power density
  • High compatibility
Key Applications
  • Mobile phone
  • Tablet PC
  • Audio & video product
  • Netcom product
  • Set top box
  1. Input
    • Input voltage：90～264Vac
    • Frequency：50/60Hz±3Hz
  2. Output
    • Output voltage/ current: 5V/1A
    • Output power: 5W
    • Over voltage protection: The adapter shall resume normal operation when the fault condition is removed.
    • Over current protection: It will automatically recover at 110-200% of rated load
    • Short circuit protection: The adapter shall resume normal operation when the fault condition is removed.
    • Operating temperature: 0~40℃
    • Operating humidity: 10%~90% RH
    • Non-Operating temperature: -20℃~ +80℃
  3. Safety standards
    • UL 60950-1
    • EN /IEC 60950-1
    • GB 4943
    • BS EN60950-1
    • AS/NZS60950-1
    • J 60950
  4. Certificates and approvals
    • CB CE GS T-Mark
    • UL-CUL FCC
    • SAA
    • CCC
    • PSE
  5. EMI Emission
    • Radiation & Conduction Test: FCC part 15, EN 55032, GB9254, GB17625.1.
    • Harmonic Test: EN 61000-3-2
    • Flicker Test: EN 61000-3-3
  6. EMS immunity
    • ESD Test: EN 61000-4-2
    • RS Test: EN 61000-4-3
    • EFT Test: EN 61000-4-4
    • Surge Test: EN 61000-4-5
    • CS Test: EN 61000-4-6
    • DIP Test: EN 61000-4-11
Certificates and approvals
