SPS wall-mount
24W KSA-24W SERIES
EXTERNAL POWER SUPPLIES
Key Features
- Compact and smooth design
- Green power, full complies with CEC level V, MEPS V EUP2011
- High power density
- Extra safe design, have got their respective safety approvals
- Completed protect function
Key Applications
- ADSL
- Set top box
- Audio & Video product
- Home appliance
- Notebook
- mobile hard disk
- Netcom products
-
Input
- Input voltage:90~264Vac
- Frequency:50/60Hz±3Hz
-
Output
- Output voltage: 9-24V
- Output current: 0.01A-2.5A
- Output power: 24W max
- Over voltage protection: The adapter shall resume normal operation when the fault condition is removed.
- Over current protection: It will automatically recover at 110-200% of rated load
- Short circuit protection: The adapter shall resume normal operation when the fault condition is removed.
- Operating temperature: 0℃~40℃
- Operating humidity: 10%~90% RH
- Non-Operating temperature: -20℃~80℃
-
Safety standards
- IEC/EN 60950-1/60065
- UL 60950-1
- GB4943
-
Certificates and approvals
- CB , GS , CE-LVD
- UL-CUL , FCC
- CCC
- SAA, RCM, GEMS
-
EMI Emission
- Radiation & Conduction Test: EN 55032/FCC Part 15
- Harmonic Test: EN 61000-3-2
- Flicker Test: EN 61000-3-3
-
EMS immunity
- ESD Test: EN 61000-4-2
- RS Test: EN 61000-4-3
- EFT Test: EN 61000-4-4
- Surge Test: EN 61000-4-5
- CS Test: EN 61000-4-6
- DIP Test: EN 61000-4-11
