Products

Sps Desk Top

30W KSUS030 Slim Series

external power supplies
Key Features
  • Light, extra slim, sleek, compact design
  • Green power, full complies with CEC level V, MEPS V EUP2011
  • High power density
  • Extra safe design, have got their respective safety approvals
  • Completed protect function
Key Applications
  • Mobile Devices
  • Laptop
  • Printer
  • Pos
  • Set-top-box
  • ADSL
  • Hard disk drive
  • Audio & Video product
  • Household appliance
  1. Input
    • Input Voltage: 90 to 264 VAC
    • Frequency : 47-50/60-63hz
    • Input current : 0.8A (Max) 100 /240VAC
    • Inrush current : 60A Max 120VAC at max Load
    • 100A Max 240VAC at max Load
    • Leakage current: 0.25 mA Max
  2. Output
    • Over voltage protection
    • Over current protection
    • at 110-200% of lo and Auto-recovery
    • Electronic short circuit protection
    • Operating temperature 0~40℃ Free convection
    • Operating humidity 10-90% RH Non Condensing
    • Sea level Non-operating temperature -20~ 80℃
  3. Safety standards
    • Information technology equipment
    • IEC/EN 60950-1, UL 60950-1, CSA C22.2
    • No. 60950-1-03,GB4943
  4. Certificates and approvals
    • CB , GS , CE , TUV, UL , CCC , FCC,PSE,C-TICK
  5. EMI Emission
    • Radiation Test&Conduction Test :EN 55022/FCC Part 15
    • Harmonic Test : EN 61000-3-2
    • Flicker Test : EN 61000-3-3
  6. EMS immunity
    • ESD Test:EN 61000-4-2
    • RS Test:EN 61000-4-3
    • EFT Test:EN 61000-4-4
    • Surge Test:EN 61000-4-5
    • CS Test:EN 61000-4-6
    • DIP Test:EN 61000-4-11
Certificates and approvals
