Sps Desk Top
45W KSAP0451900240M2
external power supplies
Key Features
- Light, extra slim, sleek, compact design
- High power density
- Extra safe design, have got their respective safety approvals
- Completed protect functio
Key Applications
- Laptop
- Set-top-box
- ADSL
- Hard disk drive
- Audio & Video product
- Household appliance
-
Input
- Input Voltage: 90 to 264 VAC
- Frequency : 47-50/60-63hz
- Input current : 1.2A (Max) 100 /240VAC
- Inrush current : 100A Max 120VAC at max Load
- 100A Max 240VAC at max Load
- Leakage current: 0.25 mA Max
-
Output
- Over voltage protection
- Over current protection
- at 110-200% of lo and Auto-recovery
- Over temperature protection
- Electronic short circuit protection
- Average efficiency 80% Measured at 25℃
- Operating temperature 0~35℃ Free convection
- Operating humidity 10-90% RH Non Condensing
- Sea level Non-operating temperature -20~ 80℃
-
Safety standards
- Information technology equipment
- IEC/EN 60950-1
-
Certificates and approvals
- CE
-
EMI Emission
- Radiation Test&Conduction Test:EN 55022
- Harmonic Test : EN 61000-3-2
- Flicker Test : EN 61000-3-3.
-
EMS immunity
- ESD Test:EN 61000-4-2
- RS Test:EN 61000-4-3
- EFT Test:EN 61000-4-4
- Surge Test:EN 61000-4-5
- CS Test:EN 61000-4-6
- DIP Test:EN 61000-4-11
