Sps Desk Top
Mechanical SPEC>

60W KSAP1200300200M2

external power supplies
Key Features
  • Light, extra slim, sleek, compact design
  • Green power, full complies with CEC level III,MEPS III
  • High power density
  • Extra safe design, have got their respective safety approvals
  • Completed protect function
Key Applications
  • Set-top-box
  • ADSL
  • Hard disk drive
  • Audio & Video product
  • Household appliance
  1. Input
    • Input Voltage : 90 to 264 VAC
    • Frequency : 47-50/60-63hz
    • Input current : 0.6A (Max) 10 /240VAC
    • Inrush current : 60A Max. 240VAC
    • Leakage current: 0.25 mA Max
  2. Output
    • Over voltage protection
    • Over current protection
    • Over temperature protection
    • Electronic short circuit protection
    • Peak load 4A for normal input
    • Automatic recovery
    • Ripple&noise 20MHz bandwidth: 150mV
    • Operating temperature 0~40℃ Free convection
    • Operating humidity 10-90% RH Non Condensing
    • Sea level Non-operating temperature -20~ 80℃
    • No load power less than 1W
  3. Safety standards
    • EN60950
  4. Certificates and approvals
    • Test report for EN60950
  5. EMI Emission
    • EN 55022: 1998, Class B
    • EN55024 Class B
  6. EMS immunity
    • ESD Test:EN 61000-4-2
    • RS Test:EN 61000-4-3
    • EFT Test:EN 61000-4-4
    • Surge Test:EN 61000-4-5
    • CS Test:EN 61000-4-6
    • DIP Test:EN 61000-4-11
