Sps Desk Top

120W KSAFN3000400T1M3

external power supplies
Key Features
  • Light, extra slim, sleek, compact design
  • High power density
  • Extra safe design, have got their respective safety approvals
  • Completed protect function
Key Applications
  • Printer
  • Massage armchair
  • Set-top-box
  • ADSL
  • Hard disk drive
  • Audio & Video product
  • Household appliance
  1. Input
    • Input Voltage: 90 to 264 VAC
    • Frequency : 47-50/60-63hz
    • Input current :1.2A (Max)
    • Inrush current :100A Max 120VAC at max Load
    • 100A Max 240VAC at max Load
    • Leakage current :0.25 mA Max
  2. Output
    • Over voltage protection
    • Over current protection
    • at 300% lo and.automatic-recovery
    • Over temperature protection
    • Electronic short circuit protection
    • Average efficiency 80% Measured at 25℃
    • Operating temperature 0~40℃ Free convection
    • Operating humidity 10-90% RH Non Condensing
    • Sea level Non-operating temperature -20~ 80℃
  3. Safety standards
    • Information technology equipment
    • EN 60335
  4. Certificates and approvals
    • CE
  5. EMI Emission
    • Radiation Test&Conduction Test: EN 55022/FCC Part 15
    • Harmonic Test : EN 61000-3-2
    • Flicker Test : EN 61000-3-3
  6. EMS immunity
    • ESD Test:EN 61000-4-2
    • RS Test:EN 61000-4-3
    • EFT Test:EN 61000-4-4
    • Surge Test:EN 61000-4-5
    • CS Test:EN 61000-4-6
